Item |
Value |
| General |
|
| Number of channels |
4 |
| Peak total output all channels driven |
8800W |
| Peak output voltage per channel |
141V |
| Max. output current per channel |
35.5 Arms |
|
|
| Max. Output Power |
16 ohms 8ohms 4ohms 2ohms 70Vrms/100 Vrms peak |
| Per ch. (all ch.’s driven) |
625 W 1250 W 2100 W 2200 W 2200 W |
| Bridged per ch. |
2500 W 4200 W 4600 W n.r 4) n.r 4) |
|
|
| Performance with Gain: 35 dB and VPL: 141 V |
|
| THD 20 Hz - 20 kHz for 1 W |
<0.1% |
| THD at 1 kHz and 1 dB below clipping |
<0.05% |
| Signal To Noise Ratio |
>112 dBA |
| Channel separation (Crosstalk) at 1 kHz |
>70 dB |
| Frequency response (1 W into 8 ohms) +0/-3 dB |
6.8 Hz - 34 kHz |
| Input impedance |
20 kOhm |
| Input Common Mode Rejection, CMR |
50 dB |
| Output impedance @ 100 Hz |
30 mOhm |
|
|
| Voltage Peak Limiter (VPL), max. peak output |
|
| VPL, selectable per ch. 3) |
141, 118, 100, 85, 71, 59, 50, 42 V |
| VPL, when bridged 3) 1) |
282, 236, 200, 170, 142, 118, 100, 84 V |
| Voltage Peak Limiter mode (per ch.) |
Hard / Soft |
|
|
| Gain and Level |
|
|
Amplifier gain selectable (all channels) 1)
– rear-panel switches |
23, 26, 29, 32, 35, 38, 41, 44 dB |
| Default gain |
35 dB |
|
|
| Connectors and switches |
|
| Input connectors (per ch.) |
3-pin Phoenix, electronically balanced |
| Output connectors (per ch.) |
Barrier strip 2-pole screw terminals |
| Output bridge mode |
A+B and/or C+D, inputs A and C are input source |
| NomadLink network |
On board, 2 x RJ45 connectors |
| Intelligent fans (on/off) |
Yes, depending on presence of output signal |
| Power on/off and Remote enable on/off |
Individual switches on front-panel |
| Cooling |
Two fans, front-to-rear airflow, temperature controlled speed |
|
|
| Front-panel indicators |
|
| Common |
NomadLink Network; Power Average Limiter (PAL) 2); Power on |
| Per channel |
Signal present / High-impedance; -10 dB and -4 dB output signal; Voltage Peak Limiter (VPL); Current Peak Limiter (CPL);
Very High Frequency (VHF); High Temperature; Fault; Mute |
|
|
| Power |
|
| Operating voltage, 230 V / 115 V nominal |
130 -265 / 65-135 V 5) |
| Minimum power-up voltage, 230 V / 115 V |
171 V / 85 V |
| Power Average Limiter (PAL) 2) |
Yes |
| Soft start / Inrush Current Draw |
Yes / max. 5 A |
| Mains connector |
230 V CE: 16 A, CEE7; 115 V ETL: 30 A Twist Lock |
|
|
| Dimensions (W/H/D) |
W: 483 mm (19”), H: 88 mm (2 U), D: 343 mm (13.5”) |
| Weight |
12 kg (26.4 lbs.) |
| Finish |
Black painted steel chassis with gray painted steel front |
|
|
| Approvals |
CE, ANSI/UL 60065 (ETL), CSA C22.2 NO. 60065, FCC |
